¢ñ .Product's application
TL-107, our newly developed superior modified aluminum silicate, is made up of high purity kaolinite through strictly controlled process of crushing,stripping,calcining,scattering and surface modification. It'smainly applied in nylon as modified filler, The main characteristics are as follows:
¡ô Its particle is so fine sa to sub-micron grade and the specific surface area is 16 m2/g.
¡ô It has affinity with nylon after surface modification treatment and can be filled largely.
¡ô The properties of the nylon product, mechanics,thermotics,electrical insulation and water resistance,are all improved after being filled with TL-107.According to experimental contrast, nylon produce with Ti-107 is superior to that with mica, calcium carbonate, talcum powder,etc.
¡ô It's a nucleator and efficiently reduces product shrinkage.
¡ô Products made with TL-107 have a good whiteness and can improve colorability for its high brightness.
At present, this series has been exported in batch as automobile's plastic functionality filler.
¢ò .Product's Propertie
Item product |
TL-107 |
Brightness(%) |
93¡À2 |
Particle size(-2¦Ìm%) |
80¡À2 |
Refractivity |
1.62 |
Screen Residue(325 mesh,%) |
£¼ 0.005 |
Oil Absorbency(g/100g) |
60¡À5 |
Moisture(%) |
£¼ 0.4 |
Median Particle Size(¦Ìm) |
0.5 |
¢ó .Typical Physical Properties
SiO2(%) |
Al2O3(%) |
Fe2O3(%) |
TiO2(%) |
CaO(%) |
52¡À2 |
45¡À2 |
£¼ 0.50 |
£¼ 1.5 |
£¼ 0.4 |
MgO(%) |
CuO(%) |
K2O(%) |
Na2O(%) |
MnO(%) |
£¼ 0.2 |
£¼ 0.004 |
£¼ 0.05 |
£¼ 0.15 |
£¼ 0.004 |
|
HA-90
(Calcined Kaolin Papermaking)
¢ñ .Benefits and Application
HA series, a calcined kaolin pigment, has advantages of high brightness, excellent light scattering, fine particle and low abrasion value. It can be used in filling and coating, especially in coating. Its main benefits are:
It can cut costs by replacing titaium dioxide or other expensive filling pigment.
It can improve paper's properties, such as smoothness, glossiness and opacity.
It can improve ink absorbency and print adaptation.
It has excellent compatibility with various additives.
Compared with other pigments, low viscosity of dispersed phase while the consistency is high, So It can be commpouded in high solid contedt coating and be applicable to high speed coatings.
¢ò .Typical Physical Properties
Item HA-90
Brightness(T457) 93.5%min
Particle Size(-2¦Ìm,%) 88¡À2
Abrasion Value(mg/2000 times) 3.6
Refractivity 1.62
Screen Residue(325 mesh, %) 0.003max
Oil Absorbency(g/100g) 60¡À5
Dispersion(¦Ìm) 55max
PH 5.5~7.0
Bulk Density 330kg/m3
Moisture(%) 0.8max
¢ó .Typical Chemical Properties
SiO2(%) Al2O3(%) Fe2O3(%) TiO2(%) CaO(%) MgO(%) CuO(%) K2O(%) Na2O(%) MnO(%)
52 ¡À 2 45 ¡À 2 £¼ 0.50 £¼ 1.5 £¼ 0.4 £¼ 0.2 £¼ 0.004 £¼ 0.05 £¼ 0.15 £¼ 0.004
DB-80
(Calcined Kaolin in Coatings)
¢ñ .Benefits and Application
Calcine and classification ensures DB series without any coarse particle. Therefoue, DB series has low content of 325 mesh screen residue and always keeps high Hegman grind. DB series can be applied to latex paint, powder coating and fields.
Its main benefits are:
It's the best extender of titanium dioxide with excellent opacity that can improve efficiency and cut costs by partly replacing titanium dioxide.
It can easily disperse in water or oil base after highly micronixing trturating.
Superfine particle, excellent anti-settling property gives coating good tin opening effect.
Good inert to any acid and alkali in common temperature gives coating excellent corrosion stability.
¢ò .Typical Physical Properties
Item DB-80
Brightness(T457) 93.5%min
Particle Size(-2¦Ìm,%) 80¡À2
Refractivity 1.62
Screen residue(325 mesh, %) 0.002max
Oil Absorbency(g/100g) 60¡À5
Dispersion(¦Ìm) 50max
PH 5.5~7.0
Bulk Density 330kg/m3
Moisture(%) 0.8max
¢ó .Typical Chemical Properties
SiO2(%) Al2O3(%) Fe2O3(%) TiO2(%) CaO(%) MgO(%) CuO(%) K2O(%) Na2O(%) MnO(%)
52¡À2 45 ¡À 2 £¼ 0.50 £¼ 1.5 £¼ 0.4 £¼ 0.2 £¼ 0.004 £¼ 0.05 £¼ 0.15 £¼ 0.004
HA-90T
(Calcined Kaolin in Electrophoretic Paint)
¢ñ .Benefits and Application
HA-90T series, as a calcined kaolin pigment, with the property of high brightmess, excellent light scattering, fine particle, is an extender that can replace titanium dioxide partly to improve the efficiency and replace titanium dioxide partly to improve the efficiency and reduce production costs, and can help paint to form easily the close-grained and smooth paint film.
It's hard to sedimentate and stable in electrophoresis tank.
With low impurity and good inertia, it can improve paint film's stability against corrosion and moisture-proof property.
The particle has micro platy shape. The series has advantages of low oil absorption and easy dispersion.
HA-90T, which is applied automobile electrophoresis prime coat, supplies excellent deposition stability, paint film flattening, corrosion resistance, rim angle spreadability and uniformity. Calcined kaolin's excellent opacity and adhesion make paint film flatter and denser and get much better stone striking resistance property.
¢ò .Typical Physical Properties
Item HA-90
Brightness(T457) 93.5%min
Particle Size(-2¦Ìm,%) 88¡À2
Abrasion Value(mg/2000 times) 3.6
Refractivity 1.62
Screen residue(325 mesh, %) 0.002max
Oil Absorbency(g/100g) 60¡À5
Dispersion(¦Ìm) 47.5max
PH 5.5~7.0
Bulk Density 330kg/m3
Moisture(%) 0.8max
¢ó .Typical Chemical Properties
SiO2(%) Al2O3(%) Fe2O3(%) TiO2(%) CaO(%) MgO(%) CuO(%) K2O(%) Na2O(%) MnO(%)
52 ¡À 2 45 ¡À 2 £¼ 0.50 £¼ 1.5 £¼ 0.4 £¼ 0.2 £¼ 0.004 £¼ 0.05 £¼ 0.15 £¼ 0.004
JD-80A
(Modified aluminum ailicate exclusively used in cable material)
¢ñ .Property and Application
JD-80A, a modified aluminum silicate exclusively used in cable material, is a functionality additive by our selecting superior coal series Kaolinite through the process of superfineness, refinement, calcination, and modification, It is mainly applied in EPDM cable material's formulation to improve product's insulativity. The main benefits are:
It has unique specific surface area and porous microchip structure and can improve greatly product's volume electric resistance ratio and reduce the loss of electrical energy.
It has the capacity of absorbing or intercluding free ion and can ameliorate product's thermal stability and ageing resistance.
Its super fine particle can easily disperse in basal body and it can improve product's smoothness and mechanical property.
It can make cable get long-term dielectric stability, especially in the moisture condition.
¢ò .Typical Physical Properties
Item JD-80A
Brightness(T457) 90%min
Median Particle Size(¦Ìm) 0.5max
Screen residue(325 mesh, %) 0.02max
Mohs Hardness 2
Moisture(%) 0.5max
¢ó .The Testing Data of ethylene-propylene rubber(EPDM) Cable Material with JD-80A Follows:
No. Testing Item Unit Britain(Contrast) Testing Result
1 Tensile Strength Mpa 9.0 9.0
2 Breaking Elogation % 330 360
3 Permanent Deformation % 10 10
4 Volume Resistance Before Soaking ¦¸¡¤cm 8.5¡Á1016 8¡Á1016
5 Volume Resistance After Soaking ¦¸¡¤cm 4.5¡Á1016 7¡Á1016
6 Mooney Viscosity 25 26
7 Mooney Scorching Time minute 17 15
8 Compatibility 2 2
JD-80B
(Modified aluminum silicate exclusively used in cable material)
¢ñ .Property and Application
JD-80B, a modified aluminum silicate exclusively used in cable material, is a functionslity addityve by our selecting superior coal series kaolinite through the process of superfimely grinding, refimement, calcination, and modification. It is mainly applied in PVC cable material's formulation to improve product's insulativity.
The main cenefits are:
It has unique specific surface area and porous microchip structure and it can improve greatly product's volume electric resistance ratio and reduce the loss of electrical energy.
It has the capacity is superfine and can easily disperse in basal body and it can improve product's smoothness and mechanical property.
It can make cable get long-term dielectric stability property,especially under moisture condition.
¢ò .Typical Physical Properties
Item JD-80B
Brightness(T457) 90%min
Median Particle Size(¦Ìm) 0.5max
Screen residue(325 mesh, %) 0.02max
Mohs Hardness 2
Intrinsic Density(g/cm3) 2.62
Moisture(%) 0.5max
¢ó .The Testing Data of 70 degree centigrade PVCInsulation Cable Msterial with JD-80B Follows:
No. Testing Item Unit Requirement Testing Result
1 Tensile Strength Mpa 15min 23.7
2 Breaking Elogation % 150min 284
3 Thermal Deformation % 40max 22.4
4 Impulsing & Tendering Properties ¡¡¡¡¡æ 15max eligibility
5 Thermal Stability Time at 200 ¡æ minute 60min 79
6 Volume Resistance rate at 20 ¡æ ¦¸¡¤ m 1.0 ¡Á 1012min 3.8 ¡Á 1012
7 Dielectric Strength MV/m 20min 22.3
8 Working Temperature(70 ¡æ ) ¦¸¡¤ m 1.0 ¡Á 109min 9.1¡Á1010
Volume Resistance Rate |
